Description
sizes
27.5 inches: XS,S,M 29 inches: S,M,L
colours
Metallic Black, Purple Ash
frame
ALUXX-Grade Aluminum, disc
fork
SR Suntour XCE, QR, steel steerer XS: 80mm travel (27.5) S: 100mm travel (27.5) / 100mm travel (29)
handle bar
Giant Connect Trail, 31.8mm XS: 670mm (27.5) S: 670mm (27.5) / 670mm (29) M: 750mm (27.5) / 750mm travel (29) L: 750mm (29)
grips
Giant Sole-O
stem
Giant Sport, 7-degree XS: 40mm (27.5) S: 40mm (27.5) / 40mm (29) M: 50mm (27.5) / 50mm travel (29) L: 50mm (29)
seatpost
Giant Sport, 30.9 XS: 300mm (27.5) S: 300mm (27.5) / 375mm (29) M: 375mm (27.5) / 375mm travel (29) L: 375mm (29)
saddle
Liv Sport
pedals
MTB caged
shifters
microSHIFT, 2×8
front derailleur
microSHIFT FD-M282
rear derailleur
Shimano Altus M310
brakes
Tektro HDC TKD 149, hydraulic, Tektro rotors [F]180mm, [R]160mm
brake levers
Tektro TKD 149
cassette
Shimano Deore HG200, 12×32
chain
KMC 8.3
crankset
Shimano FC-M315, 22/36 XS: 170mm (27.5) S: 170mm (27.5) / 170mm (29) M: 170mm (27.5) / 170mm travel (29) L: 175mm (29)
bottom bracket
cartridge
rims
Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
hubs
alloy, sealed bearing
spokes
stainless, 14g
tires
Kenda Booster 27.5 inches or 29×2.2 inches, wire bead
extras
2.4 inches max tire size
